Web UI

The Web UI is the built-in interface for interacting with Archon. It requires no tokens, API keys, or external services — just start the server and open your browser.

Prerequisites

Archon installed and dependencies resolved (bun install)
An Anthropic API key or Claude Code authentication (see AI Assistants)

Starting the Web UI

Development (recommended):

# Start both backend + frontend with hot reload
bun run dev
# Web UI: http://localhost:5173
# API server: http://localhost:3090

You can also start each piece individually:

# Backend API server only (port 3090)
bun run dev:server

# Frontend dev server only (port 5173, requires backend running)
bun run dev:web

Production:

bun run build    # Build the frontend into static files
bun run start    # Server serves both API and Web UI on port 3090

In production mode, the backend serves the compiled frontend at the same port (3090), so there is no separate frontend URL.

Remote / homelab access:

The backend binds to 0.0.0.0 by default. The Vite dev server only listens on localhost. To expose the frontend on your network:

bun run dev:web -- --host 0.0.0.0

Then start the backend separately with bun run dev:server. The Web UI will be reachable at http://<server-ip>:5173. Make sure your firewall allows ports 5173 and 3090.

UI Layout

The Web UI is a dark-themed single-page application with four main areas:

Conversations list — All your chat conversations, searchable and grouped by project. Click to switch, right-click or hover for rename/delete.
Project selector — Registered codebases appear here. Select a project to scope conversations and workflows to that repository. You can also register new projects (clone from URL or register a local path) and remove existing ones.
Workflow invoker — A quick-launch panel for running workflows. Select a workflow from the dropdown, type a message, and hit Run. This creates a new conversation and starts the workflow in one action.

Main Chat Area

The center of the screen is the chat interface — this is where you interact with the AI assistant. It works like any chat application, with some additions specific to coding workflows.

Command Center (Dashboard)

Accessible via the /dashboard route, the Command Center shows all workflow runs across your projects. It includes:

Status summary bar — Counts of running, completed, failed, and paused workflows
Workflow run cards — Each run shows its status, workflow name, elapsed time, and node progress
Actions — Resume, cancel, abandon, approve, or reject runs directly from the dashboard
History table — Paginated list of past runs with date range filtering

Settings

The /settings page lets you configure assistant defaults (model, provider) without editing YAML files.

Chat Interface

Creating Conversations

Click the “New Chat” button in the sidebar, or use the workflow invoker to create a conversation that immediately starts a workflow. Each conversation gets a unique ID and persists across page refreshes.

If a project is selected in the sidebar, new conversations are automatically scoped to that codebase.

Sending Messages

Type in the message input at the bottom and press Enter (or click Send). Messages can be:

Natural language — The AI assistant responds conversationally, using tools to explore and modify code
Slash commands — /status, /workflow list, /help, etc. These are handled deterministically without AI
Workflow triggers — Messages like “fix issue #42” or “review this PR” are routed to the appropriate workflow automatically

AI Responses and Tool Calls

AI responses stream in real-time. When the assistant uses tools (reading files, running commands, editing code), each tool call appears as a collapsible card showing:

The tool name and input arguments
The tool’s output or result
Expandable/collapsible to keep the chat readable

A lock indicator appears while the agent is actively working, so you know when it is safe to send another message.

Connection Status

A status indicator in the UI shows whether the SSE connection to the backend is active. If you see “disconnected”, check that the backend is running and refresh the page.

Workflow Execution

Running Workflows

There are three ways to run a workflow from the Web UI:

Sidebar workflow invoker — Select a workflow, type a message, and click Run
Chat message — Describe what you want and the router picks the right workflow (e.g., “review PR #123”)
Slash command — /workflow run <name> <message> for explicit invocation

Foreground vs Background Execution

By default, workflows run in the background — the conversation shows a progress card while the workflow executes in a separate worker conversation. You can continue chatting or start other workflows.

Workflows with interactive: true in their YAML definition run in the foreground. This is required for workflows that have approval gates or interactive loop nodes, since those need you to approve/reject steps in real time.

Workflow Progress Cards

While a workflow runs, a progress card appears in the conversation showing:

Current status (running, completed, failed, paused)
Which DAG node is currently executing
Per-node status indicators
Elapsed time

For paused workflows (approval gates), the progress card shows Approve and Reject buttons so you can control the workflow directly from the chat.

Execution Detail Page

Click on a workflow run (from the dashboard or progress card) to open the execution detail page at /workflows/runs/:runId. This shows:

The full DAG graph with per-node status
Step-by-step logs for each node
Artifacts produced by the workflow
Actions to resume, cancel, or abandon the run

Workflow Builder

The Workflow Builder at /workflows/builder provides a visual editor for creating and modifying workflow YAML files. Features include:

DAG canvas — Drag-and-drop nodes to build your workflow graph visually
Node palette — Add command, prompt, bash, and loop nodes from a sidebar library
Node inspector — Click a node to configure its properties (command, prompt text, dependencies, model overrides, hooks, MCP servers, etc.) in a tabbed panel
View modes — Toggle between Visual, Split, and Code views. Split mode shows the canvas and YAML side by side.
Command picker — Browse available commands when configuring command nodes
Validation panel — Real-time validation feedback as you build
Undo/redo — Full undo/redo stack with keyboard shortcuts
Save — Saves the workflow YAML to your project’s .archon/workflows/ directory

You can also browse existing workflows on the /workflows page and open any of them in the builder to edit.

SSE Streaming

The Web UI uses Server-Sent Events (SSE) for real-time communication with the backend. When you open a conversation, the frontend opens a persistent connection to /api/stream/:conversationId.

Events streamed over SSE include:

Event Type	Description
`text`	AI response text (batched for performance)
`tool_call`	Tool invocation with arguments
`tool_result`	Tool execution result
`workflow_step`	Workflow node status change
`workflow_status`	Overall workflow run status update
`workflow_dispatch`	Workflow started for this conversation
`dag_node`	DAG node progress update
`workflow_artifact`	Artifact produced by a workflow
`conversation_lock`	Lock/unlock indicator
`session_info`	Session metadata
`error`	Error message
`heartbeat`	Keep-alive signal

A separate dashboard SSE stream at /api/stream/__dashboard__ multiplexes workflow events across all conversations, powering the Command Center’s live updates.

Projects and Codebases

Registering a Project

From the Web UI, you can register codebases in two ways:

Clone from URL — Use the /clone <url> command in chat, or use the API to POST to /api/codebases with a url field
Register a local path — POST to /api/codebases with a path field pointing to an existing git repository

Registered codebases appear in the sidebar’s project selector.

Switching Projects

Click a project in the sidebar to scope your conversations and workflows to that codebase. The selected project determines:

Which .archon/commands/ and .archon/workflows/ are loaded
The working directory for AI tool execution
Which worktrees and isolation environments are shown

Removing a Project

Hover over a project in the sidebar and click the delete icon, or use the API to DELETE /api/codebases/:id. This removes the registration but does not delete the cloned files.
